Items | Parameter | |
Battery model | 18650 | |
Design scheme | With PCM | |
Nominal voltage | 3.7V | |
Minimum capacity | 1500mAh(1C discharge) | |
Size | D:18.2mm H:65.5mm | |
Charging voltage | 4.2V | |
Discharging cut-off voltage | 2.5V | |
Standard charging | 0.2C /4.2V | |
Max charging | 1.0C /4.2V | |
Standard discharging | 0.2C/2.5V | |
Max discharging | 1.0C/2.5V | |
Weight | Appr:46g | |
Shipment voltage | ≥3.9V | |
Battery pack impedance | ≤80mΩ | |
Operating temperature | Charging: 0°C ~ 45°C | |
Discharging: -20°C ~60°C | ||
Storage (At 50% SOC and specified temp, recoverable capacity in % vs time.) | -10°C~25°C | (12 months, ≥85%) |
-10°C ~45°C | (6 months, ≥85%) | |
-10°C~60°C | (1 month, ≥90%) | |
20±5°C is the recommended storage temperature |
Model | Nominal Voltage (V) | Nominal Capacity (mAh) | Dimension | Maximum Discharge Current | |
Diameter (mm-0.7) | Height (mm-1.0) | ||||
18650 2600 | 3.7 | 2600 | 18.5 | 65.5 | 3C |
18650 2200 | 3.7 | 2200 | 18.0 | 64.7 | 3C |
18650 2500 | 3.7 | 2500 | 18.5 | 65.5 | 3C |
18650 2400 | 3.7 | 2400 | 18 | 64.7 | 3C |
18650 2200 | 3.7 | 2200 | 18 | 64.7 | 3C |
18650 2000 | 3.7 | 2000 | 18 | 64.7 | 3C |
18650 1800 | 3.7 | 1800 | 18 | 64.7 | 3C |
18650 2500 | 3.7 | 2500 | 18 | 65 | 30A/40A |
18650 2200 | 3.7 | 2200 | 18 | 65 | 30A/35A |
18650 1500 | 3.7 | 1500 | 18 | 64.7 | 20C |
18650 1500 | 3.7 | 1500 | 18 | 64.7 | 30A/35A |
18650 1300 | 3.7 | 1300 | 18 | 64.7 | 25A |
18650 2200 | 3.7 | 2200 | 18 | 65 | 5C |
18650 2000 | 3.7 | 2000 | 18 | 65 | 5C |
18650 1800 | 3.7 | 1800 | 18 | 65 | 5C |
18650 1500 | 3.7 | 1500 | 18 | 65 | 5C |
18650 1300 | 3.7 | 1300 | 18 | 65 | 5C |
18650 3000 |
3.7 |
3000 |
18 |
65 |
|
18650 3000 |
3.85 |
3000 |
18 |
65 |
|
18650 3200 |
3.7 |
3200 |
18 |
65 |
|
Click here to find a list of other models |
D |
18.2mm |
H |
65.5mm |
